Features 1. Specially used for ultrasonic probe (ultrasonic vibrator), used to paste the connection surface between the probe and the ultrasonic vibrator plate and the stainless steel plate of the ultrasonic cleaning machine;
2. Withstand high-frequency vibration, can withstand high-frequency vibration with an ultrasonic frequency of 15KHZ-200KHZ, without falling off or breaking;
3. Under normal working conditions, it can withstand temperatures up to 150 degrees;
4. Withstand low temperatures down to minus 30 degrees Celsius, and is suitable for subzero temperatures in winter. Some glues are not hard enough at low temperatures and are brittle at low temperatures, which may cause the probe to fall off.
5. High bonding strength, in addition to hardness, the strength must also be sufficient to not fall off and break easily;
6. The glue dries quickly, starting to solidify in about 5 minutes and completely solidifying after 30 minutes. Can be tested by ultrasonic for 1 hour (short-term test). 24 hours.
7. Suitable for tight bonding between all metals. Ordinary metal AB glue cannot withstand high temperature, low temperature and high frequency vibration;
User guide It is used for the installation of ultrasonic vibration plates, ultrasonic cleaners, ultrasonic optics, ultrasonic dishwashers, ceramic filters, ultrasonic vibrating screens and other transducers. There are two ways to fix the transducer: one is welding and fixing. The second is gluing. The purpose of gluing is to ensure that there is no air or gap between the connection surface of the transducer and the stainless steel connection surface of the ultrasonic cleaner or ultrasonic vibration plate. The energy can be effectively transmitted to the water to achieve the highest possible transmission and cleaning efficiency. Without the fixed glue, the ultrasonic wave will not work, and the ordinary glue will not be able to transmit the ultrasonic wave, the ultrasonic effect.
Applicable fields 1. Suitable for ultrasonic cleaning;
2. Widely used in jewelry and glasses cleaning industry;
3. Hardware accessories and mold cleaning
4. Widely used household dishwashers
5. Electronic factory components cleaning
6. Factory circuit board cleaning
7. LED lighting industry LED cleaning
8. hospital medical equipment cleaning
9. ceramic cleaning, stainless steel
10. fiber optic ceramic parts cleaning
11. cleaning optical lenses, mobile phones and other screens;
Instructions for use AB glue is used in a 1:1 ratio around the probe screws that have been welded, or directly applied to the bottom of the probe. Let the glue enter the screw holes at the bottom. Do not touch the screws. Stir the glue evenly, then tighten the probe during the tightening process to make the glue more evenly mixed, you can turn the probe forward and backward several times during the tightening process, then tighten it again.
***Note: Do not pour the two types of glue into the container and stir evenly, which will cause the glue to react violently and float out of the container, which may lead to danger.
Dosage: Each set of glue can use about 400-500 28KHZ probes and can stick more than 500-700 40KHZ probes.
